CONTROLS, CLUTCH LEVER AND CABLE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
FULL ASSEMBLY [INCL. 2-6]
2205158
£481,45 Unit Price incl. VAT
2
KIT HOLDER SET [INCL. CLAMP AND SCREWS]
2205351
£120,36 Unit Price incl. VAT
3
KIT PIVOT PIN AND SNAP RING
2205152
£28,56 Unit Price incl. VAT
4
KIT BODY AND SWITCH [INCL. BODY SWITCH WASHER SCREW]
2205160
£361,09 Unit Price incl. VAT
5
KIT SCREWS [10 PACK]
2205391
£28,56 Unit Price incl. VAT
6
KIT LEVER ASM. [INCL. BUSHINGS AND SNAP RING]
2205159
£167,46 Unit Price incl. VAT
7
BUSHING CLUTCH/BRAKE
5139191
£24,48 Unit Price incl. VAT
8
RING RETAINING CLUTCH/BRAKE
7710747
£41,89 Unit Price incl. VAT
9
SCREW
7519958
£6,57 Unit Price incl. VAT
10
KIT COVER AND SCREW
2205161
£35,90 Unit Price incl. VAT
11
SWITCH CLUTCH
4014692
£55,93 Unit Price incl. VAT
12
KIT WASHERS [10 PACK]
2205392
£28,56 Unit Price incl. VAT
13
SCREW HXFLG
7517704
£8,45 Unit Price incl. VAT
14
CLAMP-REAR BRAKE
7080983
£5,46 Unit Price incl. VAT
15
CABLE CLUTCH
7082130
£149,85 Unit Price incl. VAT
16
E-CLIP
7710733
£4,37 Unit Price incl. VAT
17
SCREW
7517259
£6,57 Unit Price incl. VAT
18
LEVER CLUTCH PINION
5139081-425
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
